PII detector output

Introduction

The PII detector API resource returns a JSON object with this format:

{
    "success": Boolean success flag,
    "data": {
        "content": analyzed text,
        "language": language code,
        "version": technology version info,
        "knowledge": [],
        "paragraphs": [],
        "sentences": [],
        "phrases": [],
        "tokens": [],
        "entities": [],
        "extractions": [],
        "extraData": {}
    }
}

Tip

Use the live demo to see how API responses look like. Run an analysis then select the {...} json tab in the results page.

For the description of the contents, language and version properties, see the API resources output overview.

You can ignore all the arrays except extractions because they are simply functional to the production of the fundamental output that is inside the extradata object. If you are still interested, since arrays are the product of other API features, then:

For knowledgesee the description of full analysis output.
For:
- paragraphs
- sentences
- phrases
- tokens
see the description of deep linguistic analysis output.
For:
- mainSentences
- mainPhrases
- mainLemmas
- mainSyncons
- topics
see the description of keyphrase extraction output.
For entities see the description of named entity recognition output.

The extractions array and the extraData object both contain detected PII in two alternative formats.
The extractions array represents PII with a proprietary expert.ai format, while the JSON-LD property of the extraData object is a JSON-LD representation of the same information.
It's up to you to choose the format you prefer.

Simple Vs composite information

The PII detector returns simple and composite information.
Simple information—like phone numbers and e-mail addresses—have only one property. Composite information have two or more properties, like a postal address which is composed of a street name, a locality, a ZIP code and a region.

extraData object

The extraData object only property is JSON-LD, for example:

"extraData": {
    "JSON-LD": {
        "@context": {
            ...
        },
        "@graph": [
            {
                "@id": "https://schema.org/email?email=m.gut%40bfu.edu",
                "@type": "https://schema.org/email",
                "email": "[email protected]",
                "matches": [
                    {
                        "end": 211,
                        "name": "email",
                        "start": 197,
                        "value": "[email protected]"
                    }
                ]
            },
            {
                "@id": "https://schema.org/telephone?telephone=(210)%20617-5256",
                "@type": "https://schema.org/telephone",
                "matches": [
                    {
                        "end": 153,
                        "name": "telephone",
                        "start": 138,
                        "value": "(210) 617-5256"
                    }
                ],
                "telephone": "(210) 617-5256"
            },
            {
                "@id": "https://schema.org/telephone?telephone=(210)%20949-3006",
                "@type": "https://schema.org/telephone",
                "matches": [
                    {
                        "end": 181,
                        "name": "telephone",
                        "start": 166,
                        "value": "(210) 949-3006"
                    }
                ],
                "telephone": "(210) 949-3006"
            },
            {
                "@id": "https://schema.org/PostalAddress?address=7400%20Merton%20Minter%20Blvd.%2C%20San%20Antonio%2C%20TX%2C%2078229-4404",
                "@type": "https://schema.org/PostalAddress",
                "address": "7400 Merton Minter Blvd., San Antonio, TX, 78229-4404",
                "addressCountry": "United States of America",
                "addressLocality": "San Antonio",
                "addressRegion": "Texas",
                "matches": [
                    {
                        "end": 88,
                        "name": "streetAddress",
                        "start": 64,
                        "value": "7400 Merton Minter Blvd."
                    },
                    {
                        "end": 123,
                        "name": "postalCode",
                        "start": 112,
                        "value": "78229-4404"
                    },
                    {
                        "end": 123,
                        "name": "address",
                        "start": 64,
                        "value": "7400 Merton Minter Blvd., 111E, San Antonio, TX 78229-4404"
                    },
                    {
                        "end": 111,
                        "name": "addressLocality",
                        "start": 96,
                        "value": "San Antonio, TX"
                    },
                    {
                        "end": 111,
                        "name": "addressRegion",
                        "start": 96,
                        "value": "San Antonio, TX"
                    },
                    {
                        "end": 111,
                        "name": "addressCountry",
                        "start": 96,
                        "value": "San Antonio, TX"
                    }
                ],
                "postalCode": "78229-4404",
                "streetAddress": "7400 Merton Minter Blvd."
            },
            {
                "@id": "https://schema.org/Person?person=Mark%20Gutenberg",
                "@type": "https://schema.org/Person",
                "birthDate": "1984-12-08",
                "birthPlace": "Hamburg",
                "familyName": "Gutenberg",
                "gender": "M",
                "givenName": "Mark",
                "matches": [
                    {
                        "end": 54,
                        "name": "familyName",
                        "start": 39,
                        "value": "Mark Gutenberg"
                    },
                    {
                        "end": 54,
                        "name": "gender",
                        "start": 39,
                        "value": "Mark Gutenberg"
                    },
                    {
                        "end": 54,
                        "name": "givenName",
                        "start": 39,
                        "value": "Mark Gutenberg"
                    },
                    {
                        "end": 54,
                        "name": "person",
                        "start": 39,
                        "value": "Mark Gutenberg"
                    },
                    {
                        "end": 260,
                        "name": "birthPlace",
                        "start": 243,
                        "value": "HAMBURG, GERMANY"
                    },
                    {
                        "end": 282,
                        "name": "birthDate",
                        "start": 272,
                        "value": "12/8/1984"
                    }
                ],
                "person": "Mark Gutenberg"
            }
        ]
    }
}

The value of the JSON-LD property is the JSON-LD object.

The characteristic of the JSON-LD format is to provide linked data. Specifically, PII information types and properties are linked to schema.org public vocabulary definitions.
For example, the type of the information representing a postal address corresponds to the https://schema.org/PostalAddress definition and the type's properties correspond to schema.org definitions too.

For the description of the JSON-LD format refer to the official documentation.

The @graph property of the JSON-LD object contains the actual PII. @graph is an array, each item of which represents a simple or composite information.

These are all the PII that may be present:

Information type	Property	Linked data reference
Personal attributes		https://schema.org/Person
	`person`	https://schema.org/Person
	`givenName`	https://schema.org/givenName
	`familyName`	https://schema.org/familyName
	`age`	https://schema.org/Number
	`gender`	https://schema.org/gender
	`nationality`	https://schema.org/nationality
	`birthDate`	https://schema.org/birthDate
	`birthPlace`	https://schema.org/birthPlace
	`deathDate`	https://schema.org/deathDate
	`deathPlace`	https://schema.org/deathPlace
	`dateTime`*	https://schema.org/Date
Postal address		https://schema.org/PostalAddress
	`address`	https://schema.org/Text
	`streetAddress`	https://schema.org/streetAddress
	`addressCountry`	https://schema.org/addressCountry
	`addressLocality`	https://schema.org/addressLocality
	`addressRegion`	https://schema.org/addressRegion
	`postalCode`	https://schema.org/postalCode
	`postOfficeBoxNumber`	https://schema.org/postOfficeBoxNumber
Bank account		https://schema.org/BankAccount
	`IBAN`	https://schema.org/PropertyValue
	`IBANcountry`	https://schema.org/Country
IP address		https://schema.org/additionalProperty
	`IP`	https://schema.org/Text
E-mail address		https://schema.org/email
	`email`	https://schema.org/email
URL		https://schema.org/URL
	`URL`	https://schema.org/URL
Financial product (credi/debit card)		https://schema.org/FinancialProduct
	`creditDebitNumber`	https://schema.org/Text
	`CVV`	https://schema.org/Number
	`expirationDate`	https://schema.org/Date
Phone number		https://schema.org/telephone
	`telephone`	https://schema.org/telephone

* dateTime is an array, since there can be more than one value associated with the person.

The matches array of each information item contains the occurrences of the properties in the text. Each item of the array corresponds to a property. Item properties are:

name: property name
start: zero-based index of the first character of the occurrence in the text
end: zero-based index of the first character after the occurrence in the text
value: the portion of text from which the property value was taken

extractions array

To understand the contents of the extractions array you must know that information detection can also be seen as a process of extracting records of data from the text. Each record contains data fields and its structure—the possible fields—is called template.
A template can be compared to a table and the template fields to the columns of the table, as shown in the following figure.

So for example instances of the PII_PERSON template are records that contain fields like:

familyName
gender
givenName
birthPlace
birthDate

Every item of the extractions array represents an extraction record.
For example, the following item is a record that's an instance of the PII_PERSON template:

{
  "fields": [
    {
      "name": "familyName",
      "positions": [
        {
          "end": 54,
          "start": 39
        }
      ],
      "value": "Gutenberg"
    },
    {
      "name": "gender",
      "positions": [
        {
          "end": 54,
          "start": 39
        }
      ],
      "value": "M"
    },
    {
      "name": "givenName",
      "positions": [
        {
          "end": 54,
          "start": 39
        }
      ],
      "value": "Mark"
    },
    {
      "name": "person",
      "positions": [
        {
          "end": 54,
          "start": 39
        }
      ],
      "value": "Mark Gutenberg"
    },
    {
      "name": "birthPlace",
      "positions": [
        {
          "end": 260,
          "start": 243
        }
      ],
      "value": "Hamburg"
    },
    {
      "name": "birthDate",
      "positions": [
        {
          "end": 282,
          "start": 272
        }
      ],
      "value": "1984-12-08"
    }
  ],
  "namespace": "pii_en_1.0",
  "template": "PII_PERSON"
}

In each item:

namespace is the name of the software module performing the extraction.
template is the name of the template.
fields is the array of record fields.

Each item of the fields array item represents an extracted value where:

name is the field's name.
value is the field's value.
positions is an array containing the extracted field's positions.

These are all the templates and related fields:

Information type	Template	Field
Personal attributes	`PII_PERSON`
		`person`
		`givenName`
		`familyName`
		`age`
		`gender`
		`nationality`
		`birthDate`
		`birthPlace`
		`deathDate`
		`deathPlace`
		`dateTime`
Postal address	`PII_ADDRESS`
		`address`
		`streetAddress`
		`addressCountry`
		`addressLocality`
		`addressRegion`
		`postalCode`
		`postOfficeBoxNumber`
Bank account	`PII_BANKACCOUNT`
		`IBAN`
		`IBANcountry`
IP address	`PII_IP`
		`IP`
E-mail address	`PII_EMAIL`
		`email`
URL	`PII_URL`
		`URL`
Financial product (credi/debit card)	`PII_FINANCIALPRODUCT`
		`creditDebitNumber`
		`CVV`
		`expirationDate`
Phone number	`PII_TELEPHONE`
		`telephone`
